3000W 4000W 5000W CNC Laser Cutting Machine with Fiber Laser Engraver for Metal and Acrylic

Product Categories

Jiangsu Hoston Machine Tools Co., Ltd.

Contact Now

Place of Origin : Jiangsu, China

MOQ : 1

Price : $11,000-15,000

Laser type : Fiber Laser

Cutting area : 1500mm*3000mm

Cutting speed : 120mm/min

Cutting thickness : 20mm

Cooling mode : Air Cooling

Weight : 12000 KG

Max acceleration : 1.0G

Positioning accuracy : ±0.08mm

Repeated positioning accuracy : ±0.02mm

Laser power : 1500-15000W

Power consumption : 6kw

Operating voltage : 380/50

Running temperature : 0-40℃

Running humidity : <90%

Transmission : Precise rack and pinion

Contact Now

Model	1530	1540	2040	2060	2560	25120
Working Area (mm)	1500×3000	1500×4000	2000×4000	2000×6000	2500×6000	2500×12000
Machine Dimension (mm)	5000×4200×2200	6000×4200×2200	6000×4800×2200	8400×4800×2200	8500×6200×2300	15400×6700×2600
Max. Cutting Speed (mm)	120
Max. Acceleration (G)	1.0
X/Y Positioning Accuracy (mm)	±0.08
X/Y Repeated Positioning Accuracy (mm)	±0.02
Operating Voltage (V/Hz )	380/50
Laser power (W)	1500-15000
Power consumption (KW)	6
Machine Running Temperature (℃)	0-40
Machine Running Humidity	<90%
Transmission	Precise rack and pinion
